Wiring Diagram - 48v Off-Grid Pack | Victron & Energy Eco Semi-Solid State Lithium Pack 2

Name: Wiring Diagram - 48v Off-Grid Pack | Victron & Energy Eco Semi-Solid State Lithium Pack 2
Brand: Energy Eco
SKU: EE48schematic2
Price: 89.0 AUD
Availability: InStock

RRP: ~~$125.00 AUD~~
Our Price: $89.00 AUD

Sale Sold out

Tax included. FREE shipping Australia wide on orders over $300.

Product variants

Quantity

Description

Take the guesswork out of your installation. This professionally drawn schematic outlines a complete 48 V off-grid power system using Victron and Energy Eco components.

The layout includes all key system connections between:

1x MultiPlus-II 48/5000/70-50 230V - PMP482505010
1x SmartSolar MPPT 150/45 - SCC110020160R
2x Energy Eco 48V 5.12KWH Semi-Solid State Lithium Battery
1x Lynx Distributor (M10) - LYN060102010
1x Cerbo GX MK2 - BPP900451100
1x GX Touch 50 - BPP900455050
1x RJ45 UTP cable 1.8m - ASS030064950
1x Ve.Direct cable 1.8m - ASS030530218
1x Type B BMS Cable 1.8m - ASS030720018
1x Cable Kit

It also details the required but not-included protective components and solar panel connection limits.

Perfect for installers, DIY builders, and anyone wanting a clear, safe, and standards-based wiring plan.

Once purchased, the wiring diagram will be emailed to you.
